X2 Frequency Extender

60 to 90 GHz, +3 dBm Output Power, WR-12 Waveguide, E-Band
SKU:STE-2F212-03-S1
Availability:4 to 6 Weeks ARO
STE-2F212-03-S1 is an E-Band X2 frequency extender that uses an input frequency range of 30 to 45 GHz at +5 dBm along with harmonic generation and filtering to produce a 60 to 90 GHz RF signal at +3 dBm. The extender is designed and manufactured as a bench top unit to extend the low frequency synthesizer or sweeper without losing all of the functionalities and features. The extender also features adjustable legs to allow for an easy test set up.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 1$6,850.00
2 - 2$6,507.50
3 +$6,182.13

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Output Frequency60 GHz
Maximum Output Frequency90 GHz
Output Power+3 dBm
Minimum Input Frequency30 GHz
Maximum Input Frequency45 GHz
Input Power+5 dBm
DC Bias+12 V/450 mA
Output PortWR-12 Waveguide
Input Port2.4 mm (F)
