Q-Band DPDT Motorized Switch

33 to 50 GHz, 50 dB Isolation, WR-22 Waveguide
SKU:SWJ-22-TS
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWJ-22-TS is a Q band motorized double pole, double throw (DPDT) transfer switch with a TTL driver that covers the frequency range of 33 to 50 GHz. The switch has four ports and the switching is E plane. The switch is a bi-directional device which allows each port to be switched on and off between the adjacent ports. The insertion loss of the switch is 0.4 dB typical and the isolation is 50 dB typical. The switch has WR-22 waveguides with UG-383/U flanges. The bias and control signal connector is MS3112E-10-6P type. The switch can also be set manually by turning the motor can on top of the package.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $4,450.00
3 - 4 $4,227.50
5 - 9 $4,016.13

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Insertion Loss0.4 dB
Isolation50 dB
Return Loss20 dB
Bias±28 VDC/250 mA
Switching Speed125 mS
Power Handling100 W (CW)
RF PortsWR-22 Waveguide
