J-Band Fixed Attenuator, Product Discontinued

This product has been improved and is now listed as STA-06-03-F1. Read more about Limited Run Products here.

STA-06-03-F2 is a 6 dB fixed attenuator that is used in millimeterwave systems and operates from 220 to 330 GHz. The attenuator has a fixed attenuation value of 6 dB at the center frequency, 275 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Other attenuation values are available under different model numbers as STA-XX-03-F2, where XX is the desired attenuation value.
