J-Band Fixed Attenuator, High Precision

220 to 330 GHz, 6 dB, WR-03 Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-06-03-F1 is a 6 dB fixed attenuator that is used in millimeterwave systems and operates from 220 to 330 GHz. The attenuator has a fixed attenuation value of 6 dB at center frequency, 275 GHz. While the attenuator is designed for full waveguide band applications, the attenuation value does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency220 GHz
Maximum Frequency330 GHz
Attenuation6 dB @ 275 GHz
Return Loss16 dB
Power Handling100 mW
RF PortWR-03 Waveguide
Attenuator TypeFixed
