High Performance Coaxial Cable Assembly

DC to 40 GHz, 2.92 mm (M) to 2.92 mm (M), 60", Flexible
Availability:3 Days ARO
SCW-KMKM060-F1 is a 60" long, flexible, coaxial cable with 2.92 (K) mm male connectors that cover the frequency range of DC to 40 GHz. The coaxial cable utilizes high performance material and a precision manufacturing process to guarantee superior microwave performance and mechanical durability. The impedance of the cable is 50 ohms. Other lengths are offered under different models.
Login to View Pricing

Bulk Pricing

1 - 24$335.00
25 - 49$301.50
50 - 99$271.35

Bulk Pricing

Login to View Pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency40 GHz
Return Loss18 dB
Impedance50 Ohms
Cable Length60"
Cable TypeFlexible
Cable Outer Diameter0.142"
One Time Minimum Bending Radius0.7"
Connectors2.92 mm Male
