E-Band Magic Tee, Limited Run

71 to 86 GHz, 30 dB Sum and Difference Port Isolation, 20 dB Collinear Port Isolation, WR-12 Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SWM-60390320-12-SB as an alternative solution. Read more about Limited Run Products here.

SWM-71386320-12-SB is an E band magic tee that covers the frequency range of 71 to 86 GHz. This magic tee is a four-port hybrid coupler and/or power divider with two collinear arms, an E-plane (difference) arm, and an H-plane (sum) arm. The magic tee offers a 0.4 dB nominal insertion loss and high isolation between the two collinear arms and between the sum and difference arms. All waveguide ports have standard WR-12 waveguides with UG-387/U flanges.
Login to view pricing

Technical Details

Minimum Frequency71 GHz
Maximum Frequency86 GHz
Insertion Loss0.4 dB
Isolation, Sum and Difference Ports30 dB
Isolation, Collinear Ports20 dB
Return Loss15 dB
Magic Tee TypeSplit-Block
Sum and Difference PortsWR-12 WG
Collinear PortsWR-12 WG
