F-Band Externally Biased Balanced Upconverter

90 to 140 GHz, DC to 40 GHz IF, +13 dBm LO Power, WR-08 Waveguide
SKU:SFU-08-N1
Availability:3 to 5 Days ARO
SFU-08-N1 is an F-Band balanced up-converter that utilizes high performance GaAs Schottky beam-lead diodes and a balanced circuit configuration to offer superior RF performance. The mixer supports the full waveguide band operation for both LO and RF frequencies from 90 to 140 GHz with an extremely broad IF output from DC to 40 GHz. The mixer offers a conversion loss of 9 dB typical and a high RF to LO port isolation of 30 dB.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency90 GHz
Maximum RF Frequency140 GHz
Minimum LO Frequency90 GHz
Maximum LO Frequency140 GHz
Minimum IF FrequencyDC
Maximum IF Frequency40 GHz
LO Pumping Power+13 dBm
Conversion Loss9 dB
RF PortWR-08 Waveguide
