SMA Coaxial Bandpass Filter

9.9 to 10 GHz, 70 dB Rejection
SKU:SCF-10301270-SFSF-B3
Availability:6 to 8 Weeks ARO
SCF-10301270-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 9.9 to 10 GHz. The typical insertion loss of the bandpass filter is 2.5 dB and the passband ripple is ±0.4 dB. The rejection frequencies are 9.65 GHz or less and 10.25 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 18 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers. For instance, the SMA male and female configuration would be defined under model number SCF-10301270-SFSM-B3.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 9$580.00
10 - 24$522.00
25 - 49$469.80

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency9.9 GHz
Maximum Passband Frequency10 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss18 dB
Insertion Loss2.5 dB
Impedance50 Ohms
RF PortsSMA (F)
