W-Band Compact Fixed Attenuator

75 to 110 GHz, 3 dB, 1.2" Insertion Length, WR-10 Waveguide
SKU:STA-03-10-F1-C-1.2
Availability:1 Week ARO
STA-03-10-F1-C-1.2 is a compact fixed attenuator with insertion length of 1.2". The attenuator is used in millimeterwave systems and operates from 75 to 110 GHz. The attenuator has a fixed attenuation value of 3 dB at the center frequency, 92.5 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 24$490.00
25 - 49$441.00
50 - 99$396.90

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Attenuation3 dB @ 92.5 GHz
Return Loss20 dB
Power Handling0.50 W
RF PortWR-10 Waveguide
Attenuator TypeFixed
