W-Band Compact Faraday Isolator

75 to 110 GHz, 28 dB Isolation, 1.5 dB Insertion Loss, WR-10 Waveguide, 90° Twist
SKU:STF-10-91-C
Availability:4 to 6 Weeks ARO
STF-10-91-C is a full band Faraday isolator that operates from 75 to 110 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The compact, robust package is ideal for system integration and testing applications and features a 90° twist between the input port and output port. The Faraday isolator offers 28 dB typical isolation and 1.5 dB nominal insertion loss with good flatness. The input and output ports are WR-10 waveguides with UG-387/U-M flanges. An in-line configuration is available under model number STF-10-S1-C.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,100.00
5 - 9$990.00
10 +$891.00

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Insertion Loss1.5 dB
Isolation28 dB
VSWR1.4
Power Handling1.0 W
RF PortWR-10 Waveguide
