ACCESS X6 Frequency Extender

STE-SF612-16-S1-C is compact X6 frequency extender. The extender has an input frequency of 10 to 15 GHz with a typical input power of +3 dBm and an output frequency of 60 to 90 GHz with a typical output power of +16 dBm. The extender also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/850 mA. The input port configuration is a female SMA connector and the output is a WR-12 waveguide with a UG-387/U anti-cocking flange. The compact design offers a practical solution for frequency extending sources, such as Eravant Access model STL-SG-022203-S1. Self-stored calibration data with a USB-C port for fast, direct data access. Other port configurations are available under different model numbers.
