E-Band Phase Shifter, Limited Run

60 to 90 GHz, 0 to 180° Range, WR-12 Waveguide
SKU:STP-18-12-M2
Availability:Product Discontinued
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STP-18-12-M1 as an alternative solution. Read more about Limited Run Products here.

STP-18-12-M2 is an E Band, micrometer-driven WR-12 waveguide phase shifter that covers the frequency range of 60 to 90 GHz. The phase shifter has a micrometer dial which allows for repeatable phase shift settings. The E band phase shifter is an ideal piece of equipment in waveguide systems where broadband phase shifting is required. The phase shifter exhibits a 0.5 dB typical insertion loss and an adjustable phase range of up to 180 degrees.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $790.00
10 - 24 $711.00
25 - 49 $639.90

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Insertion Loss0.5 dB
Phase Shifting Range0 to 180°
Power Handling0.60 W
Input/OutputWR-12 Waveguide
