Broadband Quadrature Mixer

6 to 26.5 GHz, DC to 5 GHz IF, +18 dBm LO Power, 2.92 mm (F)
SKU:SFQ-06327315-KFKFSF-N1-M
Availability:Contact Us for Quote
SFQ-06327315-KFKFSF-N1-M is a broadband quadrature mixer that covers the frequency range of 6 to 26.5 GHz. The typical conversion loss of the quadrature mixer is 15 dB with an LO driving power of +18 dBm. The typical LO to RF port isolation is 30 dB. Since the IF port of the quadrature mixer is DC coupled, the mixer can be used as a phase detector. In addition, the mixer can be readily configured into an image rejection mixer or single sideband modulator by adding an IF quadrature coupler.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency6 GHz
Maximum RF Frequency26.5 GHz
Minimum LO Frequency6 GHz
Maximum LO Frequency26.5 GHz
Minimum IF FrequencyDC
Maximum IF Frequency5 GHz
LO Pumping Power+18 dBm
Conversion Loss15 dB
RF Port2.92 mm (F)
