V-Band Magic Tee, Wellprice

This is a Wellprice model that may not be offered in the future. Customers who anticipate long-term requirements should consider SWM-50370320-15-SB as an alternative solution. Read more about Wellprice Products here.

SWM-50370315-15-SB-WP is a V band magic tee that covers the frequency range of 50 to 70 GHz. This magic tee is a four-port hybrid coupler and/or power divider with two collinear arms, an E-plane (difference) arm, and an H-plane (sum) arm. The magic tee offers a 0.3 dB nominal insertion loss and high isolation between the two collinear arms and between the sum and difference arms. All waveguide ports have standard WR-15 waveguides with UG-385/U flanges.
