U-Band Linear to Circular Polarizer

49 GHz Center, 1.1 Axial Ratio, 0.188" Diameter Circular Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAS-493-18819-F1 is an U band, linear to circular polarizer that operates at 49 GHz with a ±3.3 GHz bandwidth. The polarizer offers a typical insertion loss of 0.5 dB, a typical axial ratio of 1.1, and a typical return loss of 20 dB. The polarizer is fixed and can be used for either right-handed or left-handed polarization based on the direction of the input signal. The polarizer is often combined with SAGE Millimeter’s rectangular to circular waveguide transition (SWT-19188-SB) and WR-19 conical horn antenna (SAC-2309-188-S2) for various system applications.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency49 GHz
Bandwidth±3.3 GHz
Insertion Loss0.5 dB
Axial Ratio1.1
Return Loss20 dB
Input/Output0.188" Diameter Circular Waveguide
