U-Band Junction Circulator

43.5 to 45.5 GHz, 20 dB Isolation, WR-19 Waveguide
SKU:SNW-4434630520-19-C1
Availability:4 to 6 Weeks ARO
SNW-4434630520-19-C1 is a U band waveguide junction circulator that covers the frequency range of 43.5 to 45.5 GHz. The circulator is a key component in any radar and communication system where the duplexing functions are required. The waveguide junction circulator is manufactured to offer the highest performance. The circulator is designed and manufactured to provide a low insertion loss of 0.5 dB and an isolation of 20 dB typically, which offers the broadest the bandwidth in the class. The ports are WR-19 waveguides with UG-383/U-M flanges. Various configurations and frequency ranges are offered under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$820.00
10 - 24$738.00
25 +$664.20

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency43.5 GHz
Maximum Frequency45.5 GHz
Insertion Loss0.5 dB
Isolation20 dB
Return Loss17 dB
Power Handling5 W (CW)
Reverse Power Handling-
RF PortWR-19 Waveguide
Device TypeCirculator
