U-Band Compact Fixed Attenuator

40 to 60 GHz, 3 dB, 2.0" Insertion Length
SKU:STA-03-19-F1-C-2.0
STA-03-19-F1-C-2.0 is a compact fixed attenuator with an insertion length of 2.0”. The attenuator is used in millimeterwave systems and operates from 40 to 60 GHz. The attenuator has a fixed attenuation value of 3 dB at the center frequency, 50 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Other attenuation values are available under different model numbers as STA-XX-19-F1-C-2.0, where XX is the desired attenuation value.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $490.00
25 - 49 $441.00
50 - 99 $396.90

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Attenuation3 dB @ 50 GHz
Return Loss20 dB
Power Handling0.5 W (CW) (Max)
RF PortWR-19 Waveguide
Attenuator TypeFixed
