X4 Frequency Extender

40 to 60 GHz, +20 dBm Adjustable Output Power, WR-19 Waveguide, U-Band
STE-SF419-S1 is a U-Band X4 frequency extender that uses an input frequency range of 10 to 15 GHz at +0 dBm along with harmonic generation and filtering to produce a 40 to 60 GHz RF signal. The extender is designed and manufactured as a bench top unit to extend the low frequency synthesizer or sweeper without losing all of the functionalities and features. The extender also features adjustable legs, which can also be removed, to allow for an easy test set up.
ECCN: 3A001.b.7
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency40 GHz
Maximum Output Frequency60 GHz
Output Power+20 dBm
Minimum Input Frequency10 GHz
Maximum Input Frequency15 GHz
Input Power0 dBm
Power Supply100 VAC to 240 VAC
Output PortWR-19 Waveguide
Input PortSMA (F)
