Ka-Band Power Amplifier with Uni-Guide™

37 to 40 GHz, 30 dB Gain, +27 dBm P1dB, In-line WR-28 Waveguide
SBP-3734033027-2828-E1 is a power amplifier with a typical small signal gain of 30 dB and a nominal P1dB of +27 dBm across the frequency range of 37 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/1,800 mA. The mechanical configuration is an inline structure with WR-28 Uni-Guide™ waveguides and UG-599/U flange. Other port configurations, such as K connectors and WR-28 waveguides for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency37 GHz
Maximum Frequency40 GHz
Gain30 dB
P1dB+27 dBm
Psat+29 dBm
Input Return Loss5 dB
Output Return Loss10 dB
DC Voltage+8 VDC
DC Bias1800 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide
