Ka-Band Volume Production Oscillator

37 GHz, ±0.50 GHz Tuning Bandwidth, +11 dBm Output Power, WR-28 Waveguide
SKU:SOL-37311-28-G1
Availability:1 Week ARO
SOL-37311-28-G1 is a volume-production ready, Ka Band Gunn oscillator that utilizes a high performance GaAs Gunn diode and high Q cavity to achieve excellent phase noise and power stability. The oscillator is designed for fixed frequency applications, however, the frequency can be adjusted by ±0.5 GHz using the self-locking set screw provided.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$490.00
10 - 24$441.00
25 +$396.90

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Center Frequency37 GHz
Output Power+11 dBm
Mechanical Tuning Range±500 MHz
Varactor Tuning Range-
Phase Noise-95 dBc/Hz @ 100 KHz offset
Bias+5.5 VDC/350 mA
Varactor Tuning Voltage Range-
RF PortWR-28 Waveguide
