Ka-Band Low Noise Amplifier with Uni-Guide™

33 to 37 GHz, 40 dB Gain, 3.0 dB Noise Figure, In-line WR-28 Waveguide
SBL-3333734030-28KF-E1 is a low noise amplifier with a typical small signal gain of 40 dB and a nominal noise figure of 3 dB across the frequency range of 33 to 37 GHz. The DC power requirement for the amplifier is +8 VDC/205 mA. The mechanical configuration is an inline structure with WR-28 Uni-Guide™ waveguide as its input port and K(F) connector as its output port. Other port configurations, such as K connectors and WR-28 waveguides for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency37 GHz
Gain40 dB
Noise Figure3.0 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/205 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide/2.92 mm (F)
