Beam Switchable Transmitter Assembly

27 to 29 GHz, Ka-Band, 7 Channels
SKU:SST-2830231719-28-S1
Availability:Contact Us for Quote
SST-2830231719-28-S1 is a Ka Band transmitter with seven antenna outputs and one coaxial output for calibration. The transmitter can be operated at the frequency range 27 to 29 GHz. The transmitter utilizes an SP8T with 100 ns switching speed for a total coverage of 126°. The transmitter can be paired with the SSR-2830233605-28-S1 for measuring signal strength for 5G and object detection etc. applications.
ECCN: EAR99
Login to view pricing

Technical Details

SpecificationsRF Frequency Range: 27 to 29 GHz
Antenna 3 dB Beamwidth: 18°
Antenna Gain: 20 dBi
Antenna Polarization: Linear
Transmitter Gain: 19 dB
Transmitter P-1dB: 17 dBm
Switch Speed: 100 ns
System Gain: 39 dB
RF Input Port (7X): WR-28 Waveguide
RF Output Port (1X): 2.92 mm (F) Connector
