2.92 mm Coaxial Bandpass Filter

27 to 28.5 GHz, 50 dB Rejection
SKU:SCF-28315250-KFKF-B3
Availability:6 to 8 Weeks ARO
SCF-28315250-KFKF-B3 is a coaxial bandpass filter with a passband frequency of 27 to 28.5 GHz. The typical insertion loss of the bandpass filter is 2 dB and the passband ripple is ±0.5 dB. The rejection frequencies are 25.5 GHz or less and 30 GHz to 40 GHz. The typical rejection is 50 dB and the typical passband return loss of the filter is 12 dB. The RF connectors of the the filter are 2.92 mm Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,850.00
5 - 9 $1,665.00
10 - 24 $1,498.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency27 GHz
Maximum Passband Frequency28.5 GHz
Low Side Rejection50 dB
High Side Rejection50 dB
Return Loss12 dB
Insertion Loss2 dB
Impedance50 Ohms
RF Ports2.92 mm (F)
