X2 Active Frequency Multiplier with Uni-Guide™

SFA-282SF-E1 is an active X2 frequency multiplier. The multiplier has an input frequency of  13.25 to 20 GHz with a typical input power of +5 dBm and an output frequency of 26.5 to 40 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/420 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.
