Ka-Band Low Noise Amplifier with Uni-Guide™

24 to 42 GHz, 30 dB Gain, 3.5 dB Noise Figure, In-line WR-28 Waveguide
SKU:SBL-2434233035-2828-E1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-2434233035-2828-E1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 3.5 dB across the frequency range of 24 to 42 GHz. The DC power requirement for the amplifier is +8 VDC/550 mA. The RF connectors are WR-28 Uni-Guide™ waveguides. Other port configurations, such as K connectors for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $2,500.00
3 - 4 $2,375.00
5 - 9 $2,256.25

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency24 GHz
Maximum Frequency42 GHz
Gain30 dB
Noise Figure3.5 dB
P1dB+20 dBm
Input Return Loss5 dB
Output Return Loss10 dB
DC Bias+8 VDC/66 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide
