K-Band Single Channel, Ranging Sensor Module

24.125 GHz,+7 dBm Transmitting Power
SKU:SSP-24307-S1
Availability:3 Days ARO
SSP-24307-S1 is a K band ranging sensor module based on FMCW radar principles. This sensor module is designed and manufactured for short range measurements of a moving target's speed. The sensor module has a center frequency of 24.125 GHz and takes a nominal bias of +5.0 VDC/250 mA. The frequency modulation bandwidth of ±100 MHz minimum is realized via a tuning voltage of 0 to +20 Volts. The sensor modules are configured with a T/R diplexer, a single channel receiver and a transmitter/receiver oscillator in a die-cast housing. Various antennas can be integrated with the module to form sensor heads for many system applications.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$720.00
10 - 24$648.00
25 +$583.20

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

RF Center Frequency24.125 GHz
TX Power+7 dBm
FMCW Tuning Bandwidth±100 MHz
FMCW Tuning Voltage0 to +20 Volts
Minimum IF FrequencyDC
Maximum IF Frequency100 MHz
Frequency Stability-0.8 MHz/°C
DC Bias+5 VDC/250 mA
ChannelSingle
