Ka-Band Power Amplifier with Uni-Guide™

22 to 40 GHz, 17 dB Gain, +23 dBm P1dB, WR-28 Waveguide, 2.92 mm (F)
SKU:SBP-2234031723-28KF-E1
Availability:1 to 2 Weeks ARO
SBP-2234031723-28KF-E1 is a power amplifier with a small signal gain of 17 dB and a nominal P1dB of +23 dBm across the frequency range of 22 to 40 GHz. The amplifier exhibits moderate gain and 10 dB typical input and output return loss. The DC power requirement for the amplifier is +8 VDC/500 mA. The mechanical configuration is an inline structure with a WR-28 Uni-Guide™ waveguide as input and K(F) connector as output. Other port configurations, such as male K connectors or WR-28 Waveguide for either the input or output port, are also available under different model numbers.
ECCN: 3A001.b.4.e.1
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$2,600.00
3 - 4$2,470.00
5 +$2,346.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency22 GHz
Maximum Frequency40 GHz
Gain17 dB
P1dB+23 dBm
Psat+24 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/500 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide/2.92 mm (F) Connector
