K-Band Linear to Circular Polarizer

22.5 GHz Center, 1.1 Axial Ratio, 0.396" Diameter Circular Waveguide
SKU:SAS-233-39642-F1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAS-233-39642-F1 is a K band, linear to circular polarizer that operates at 22.5 GHz with a ±2.5 GHz bandwidth. The polarizer offers a maximum insertion loss of 1.0 dB, a typical axial ratio of 1.1, and a typical return loss of 20 dB. The polarizer is fixed and can be used for either right-handed or left-handed polarization based on the direction of the input signal. The polarizer is often combined with Eravant’s rectangular to circular waveguide transition (SWT-42396-SA) and WR-42 conical horn antenna (SAC-2309-396-S2) for various system applications.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency22.5 GHz
Bandwidth± 2.5 GHz
Insertion Loss0.5 dB
Axial Ratio1.1
Return Loss20 dB
Input/Output0.396" Diameter Circular Waveguide
