K-Band Conical Horn Antenna

23 dBi Gain, 20 to 24.5 GHz, 0.396" Diameter Circular Waveguide
SKU:SAC-2309-396-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAC-2309-396-S2 is a K-band conical horn antenna that operates from 20 to 24.5 GHz. The antenna offers 23 dB nominal gain and a typical half powerbeam width of 11 degrees on the E-plane and 13 degrees on the H-plane. The horn also offers typical sidelobes of -20 dB on the E-plane and -28 dB on the H-plane. The conical horn can support linear and circular polarization. The input of this antenna is a 0.396" diameter circular waveguide with UG-595/U-M flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 9$650.00
10 - 24$585.00
25 - 49$526.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency20 GHz
Maximum Frequency24.5 GHz
Gain23 dBi
3 dB Beamwidth, E-Plane11°
3 dB Beamwidth, H-Plane13°
Return Loss23 dB
PolarizationLinear and Circular
Antenna Port0.396" Dia Circular WG
