K-Band Receiver

21 to 27 GHz, 4 dB Noise Figure, 3 dB RF to IF Conversion Gain
SKU:SSR-2430630060-42-S1
Availability:1 to 2 Weeks ARO
SSR-2430630060-42-S1 is a K-Band receiver. The receiver has a typical conversion gain of 3 dB with a typical RF input P-1 dB of -5 dBm in the frequency range of 21.0 to 27.0 GHz and a IF output frequency range of DC to 4.0 GHz. The required LO power and frequency range are +0 dBm and 12.0 GHz. The LO and IF port are both equipped with female SMA connectors and the RF port is a WR-42 waveguide with a UG595/U flange. K(F) RF port option is availabe under a different model number.
ECCN: EAR99
To view pricing or check order status

Technical Details

RF Input Minimum Frequency21 GHz
RF Input Maximum Frequency27 GHz
Conversion Gain3 dB
LO Frequency12 GHz
LO Input Power0 dBm
Bias Voltage10 VDC
RF PortWR-42 Waveguide
