Broadband Power Amplifier, Product Discontinued

20 to 55 GHz, 35 dB Gain, +25 dBm P1dB, 1.85 mm (F)
SKU:SBP-2035533529-VFVF-S1-HR
Availability:Product Discontinued
Select up to 4 products to compare.
Select up to 4 products to compare.
This product has been improved and is now listed as SBP-2035533526-VFVF-H1-HR. Read more about Limited Run Products here.

SBP-2035533529-VFVF-S1-HR is a broad-band power amplifier that operates in 20 to 55 GHz and delivers nominal gain of 35 dB. The DC power requirement for the amplifier is +8 VDC/2.2 A. The RF connectors are female 1.85 mm connectors. Other port configurations, such as 2.4 mm connectors or waveguide interface for either the input or output port, are also available under different model numbers and may have different speifications depending on operating range.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency20 GHz
Maximum Frequency55 GHz
Gain35 dB
P1dB+25 dBm
Psat+26 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Voltage+8 VDC
DC Bias2200 mA
RF Input/Output1.85 mm (F)
ConfigurationHeatsink Included
