X4 Active Frequency Multiplier

20 to 50 GHz, +10 dBm Output Power, SMA (F) Input, 2.4 mm (F) Output
SFA-203503410-2FSF-S1 is an active X4 frequency multiplier. The multiplier has an input frequency of 5 to 12.5 GHz with a typical input power of +0 dBm and an output frequency of 20 to 50 GHz with a typical output power of +10 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port is a female SMA connector and the output is a female 2.4 mm connector. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,450.00
3 - 4 $3,277.50
5 - 9 $3,113.63

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency20 GHz
Maximum Output Frequency50 GHz
Output Power+10 dBm
Minimum Input Frequency5 GHz
Maximum Input Frequency12.5 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output Port2.4 mm (F)
Input PortSMA (F)
