WR-19 Waveguide Rectangular Horn Antenna

20 dBi Gain, 40 to 60 GHz, U-Band
SKU:SAR-2013-19-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2013-19-S2 is a U-band pyramidal horn antenna that operates from 40 to 60 GHz. The antenna offers 20 dBi nominal gain and a typical half power beamwidth of 14 degrees on the E-plane and 16 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-19 waveguide with UG-383/U-M flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $600.00
10 - 24 $540.00
25 - 49 $486.00

Bulk Availability

QuantityAvailability
1 - 28In Stock

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Gain20 dBi
3 dB Beamwidth, E-Plane14°
3 dB Beamwidth, H-Plane16°
Return Loss23 dB
Antenna PortWR-19 Waveguide
