WR-08 Waveguide Rectangular Horn Antenna

20 dBi Gain, 90 to 140 GHz, F-Band
SKU:SAR-2013-08-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2013-08-S2 is an F-band pyramidal horn antenna that operates from 90 to 140 GHz. The antenna offers 20 dBi nominal gain and a typical half power beamwidth of 16 degrees on the E-plane and 18 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-08 waveguide with UG-387/U-M flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $650.00
10 - 24 $585.00
25 - 49 $526.50

Bulk Availability

QuantityAvailability
1 - 12In Stock

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency90 GHz
Maximum Frequency140 GHz
Gain20 dBi
3 dB Beamwidth, E-Plane16°
3 dB Beamwidth, H-Plane18°
Return Loss23 dB
Antenna PortWR-08 Waveguide
