Broadband Subharmonically Pumped Mixer

18 to 40 GHz RF, 9 to 20 GHz LO, 1.0 to 2.0 GHz IF, +13 dBm LO Power, 2.92 mm (F)
SKU:SFS-18340315-KFSFSF-N1-M
Availability:1 to 2 Weeks ARO
SFS-18340315-KFSFSF-N1-M is a broad band subharmonically pumped mixer that utilizes a high performances GaAs MMIC to offer superior RF performance. The mixer provides a conversion loss of 15 dB over the RF frequency range of 18 to 40 GHz with the IF frequency of 1.0 to 2.0 GHz. The mixer requires an LO signal from 9 to 20 GHz at a nominal +13 dBm. In addition, the subharmonically pumped mixer offers high LO to IF and RF to LO isolations.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$2,050.00
5 - 9$1,845.00
10 +$1,660.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum RF Frequency18 GHz
Maximum RF Frequency40 GHz
Minimum LO Frequency9 GHz
Maximum LO Frequency20 GHz
Minimum IF Frequency1.0 GHz
Maximum IF Frequency2.0 GHz
LO Pumping Power+13 dBm
Conversion Loss15 dB
RF Port2.92 mm (F)
