K-Band Low Noise Amplifier

18 to 26.5 GHz, 20 dB Gain, 2.5 dB Noise Figure, 2.92 mm (F)
SKU:SBL-1832732025-KFKF-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-1832732025-KFKF-S1 is a low noise amplifier with a typical small signal gain of 20 dB and a nominal noise figure of 2.5 dB across the frequency range of 18 to 26.5 GHz. The DC power requirement for the amplifier is +8 VDC/130 mA. The RF connectors are female K connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,750.00
5 - 9 $1,575.00
10 - 24 $1,417.50

Bulk Availability

QuantityAvailability
1 In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain20 dB
Noise Figure2.5 dB
P1dB+18 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/130 mA
RF Input/Output2.92 mm (F)
