SMA Coaxial Bandpass Filter

17 to 18 GHz, 70 dB Rejection
SCF-18301370-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 17 to 18 GHz. The typical insertion loss of the bandpass filter is 1 dB and the passband ripple is ±0.4 dB. The rejection frequencies are 15.5 GHz or less and 19.5 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 16 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency17 GHz
Maximum Passband Frequency18 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss16 dB
Insertion Loss1 dB
Impedance50 Ohms
RF PortsSMA (F)
