SMA Coaxial Bandpass Filter

16.94 to 17.34 GHz, 40 dB Rejection
SKU:SCF-17304240-SFSF-B3-2
Availability:6 to 8 Weeks ARO
SCF-17304240-SFSF-B3-2 is a coaxial bandpass filter with a passband frequency of 16.94 to 17.34 GHz. The typical insertion loss of the bandpass filter is 1.5 dB and the passband ripple is ±0.3 dB. The rejection frequencies are 16.54 GHz or less and 17.74 GHz or higher. The typical rejection is 40 dB and the typical passband return loss of the filter is 18 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 9$760.00
10 - 24$684.00
25 - 49$615.60

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency16.94 GHz
Maximum Passband Frequency17.34 GHz
Low Side Rejection40 dB
High Side Rejection40 dB
Return Loss18 dB
Insertion Loss1.5 dB
Impedance50 Ohms
RF PortsSMA (F)
