WR-28 Waveguide Square Horn Antenna

15 dBi Gain, 23 to 44 GHz, Ka-Band
SKU:SAR-1532-280-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAR-1532-280-S2 is a square horn antenna that operates from 23 GHz to 44 GHz. The antenna offers 15 dBi nominal gain and a typical half power beamwidth of 22 degrees on the E-plane and 32 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a 0.28" X 0.28" waveguide with UG-599/U-M Flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency23 GHz
Maximum Frequency44 GHz
Gain15 dBi
3 dB Beamwidth, E-Plane22°
3 dB Beamwidth, H-Plane32°
Return Loss25 dB
Antenna Port0.28" x 0.28" Square WG
