8-Way Coaxial Power Splitter

12.4 to 18 GHz, SMA (F)
SKU:SCS-1231831616-SFSF-82
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCS-1231831616-SFSF-82 is a coaxial 8-way power splitter with a typical insertion loss of 1.6 dB at each output port and a typical isolation of 16 dB across the frequency range of 12.4 to 18 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±0.8 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $530.00
10 - 24 $477.00
25 - 49 $429.30

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency12.4 GHz
Maximum Frequency18 GHz
Ways8
Insertion Loss1.6 dB
Port Isolation16 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
