D-Band Compact Faraday Isolator

110 to 170 GHz, 30 dB Isolation, 3 dB Insertion Loss, WR-06 Waveguide
SKU:STF-06-S1-C
Availability:4 to 6 Weeks ARO
STF-06-S1-C is a full band Faraday isolator that operates from 110 to 170 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The compact, robust package is ideal for system integration and testing applications. The Faraday isolator offers 28 dB typical isolation and 3 dB nominal insertion loss with good flatness. The input and output ports are WR-06 waveguides with UG-387/U-M flanges. A 90° twist configuration is available under model number STF-06-91-C.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,850.00
5 - 9$1,665.00
10 +$1,498.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss3 dB
Isolation28 dB
VSWR1.5
Power Handling0.8 W
RF PortWR-06 Waveguide
