WR-42 Waveguide to Coax Adapter

WR-42 Waveguide to 2.92 mm (F), End Launch
SKU:SWC-42KF-E1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWC-42KF-E1 is an end launch (180°) K-Band waveguide to coax adapter that covers the frequency range of 18 to 26.5 GHz. The adapter is designed and manufactured for instrumentation grade quality but offered at a commercial grade price, allowing for an efficient transition between the rectangular waveguide and 2.92 mm (K) coax connector. The right angle (90°) version is offered under model number SWC-42KF-R1.
ECCN: EAR99
Login to view pricing

Bulk Pricing

QuantityPrice
1 - 24$320.00
25 - 49$288.00
50 +$259.20

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Insertion Loss0.3 dB
Return Loss20 dB
Power Handling50 W
Waveguide PortWR-42 Waveguide
Coax TypeK (2.92 mm)
Coax GenderFemale
ConfigurationEnd Launch (180°)
