WR-19 Waveguide Open

U-Band, Fixed
SKU:SWO-19-F1
Availability:4 to 6 Weeks ARO
SWO-19-F1 is a fixed waveguide open with a UG-383/U-M flange covering the frequency range from 40 to 60 GHz. The product consists of a waveguide short (model number SWS-QU-F1) and a ¼ ?g waveguide shim (model number SWI-19076-SB). The waveguide is 0.076" thick offering perfect open at the center frequency of 50 GHz when combined with the waveguide short. The product is manufactured with a precision machining process to ensure high quality and ruggedness. The open offers good reflection in the entire frequency range.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$330.00
25 - 49$297.00
50 +$267.30

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Length0.076"
Waveguide FlangeUG-383/U-M Flange
Waveguide Short TypeFixed
