WR-15 Waveguide Open

V-Band, Fixed
SKU:SWO-15-F1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWO-15-F1 is a fixed waveguide open with a UG-385/U flange covering the frequency range from 50 to 75 GHz. The product consists of a waveguide short (model number SWS-VG-F1) and a ¼ ?g waveguide shim (model number SWI-15061-SB). The waveguide shim is 0.061" thick offering perfect open at the center frequency of 62.5 GHz when combined with the waveguide short. The product is manufactured with a precision machining process to ensure high quality and ruggedness. The open offers good reflection in the entire frequency range.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 24$330.00
25 - 49$297.00
50 - 99$267.30

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Length0.061"
Waveguide FlangeUG-385/U Flange
Waveguide Short TypeFixed
