45° H-Plane Waveguide Bend

WR-06 Waveguide, D-Band, 0.75" Bend Radius
SKU:SWB-06045-HB
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWB-06045-HB is a 45 degree, WR-06 H-plane waveguide bend with UG-387/U-M anti-cocking flanges. The bend radius is 0.75”. The waveguide bend is manufactured through a precision machining process to ensure high quality and ruggedness. The waveguide is offered to cover the frequency range of 110 to 170 GHz. The waveguide is also available in instrumentation grade.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Angle45 Degrees
OrientationH-Plane Bend
Bend Radius/Length0.75"
Waveguide SizeWR-06
