1.85 mm (F) Metrology Grade Coaxial Short

DC to 67 GHz, 20:1 VSWR
SKU:STQ-CS-VF-U2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STQ-CS-VF-U2 is a metrology grade 1.85 mm (V) female short that covers the frequency range of DC to 67 GHz. The coaxial short exhibits a typical VSWR higher 20:1 It is designed and manufactured to offer a good short for system applications. The male version is available under the model number STQ-CS-VM-U2.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency67 GHz
VSWR20
Connector1.85 mm Female
