High Performance Coaxial Cable Assembly

DC to 26.5 GHz, SMA (M) to SMA (M), 60", Flexible, Phase Matched, Lab Grade
SKU:SCW-SMSM060-F1-A-PM
SCW-SMSM060-F1-A-PM is a 60" long, flexible, phase matched lab grade coaxial cable with SMA male connectors that cover the frequency range of DC to 26.5 GHz. The coaxial cable utilizes high performance material and a precision manufacturing process to guarantee superior microwave performance and mechanical durability. The impedance of the cable is 50 ohms. Other lengths are offered under different models.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency26.5 GHz
Return Loss20 dB
Impedance50 Ohms
Cable Length60"
Cable TypeFlexible
Cable Outer Diameter0.181"
Minimum Bending Radius0.79"
ConnectorsSMA Male
