High Performance Coaxial Cable Assembly

DC to 110 GHz, 1 mm (M) to 1 mm (M), 6" Semi-Rigid
SKU:SCW-1M1M006-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCW-1M1M006-S1 is a 6" long, semi-rigid coaxial cable with 1 mm male connectors that cover the frequency range of DC to 110 GHz. The coaxial cable has an impedance of 50 ohms and a capacitance of 95 pF/m. This coax cable is also offered with female connectors under model number SCW-1F1F006-S1. Additionally, other lengths are offered under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$2,050.00
5 - 9$1,845.00
10 +$1,660.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency110 GHz
Return Loss13 dB
Impedance50 Ohms
Cable Length6"
Cable TypeSemi-Rigid
Cable Outer Diameter0.047"
Minimum Bending Radius0.126"
Connectors1 mm Male
