W-Band Mechanically Tuned Gunn Oscillator

SOM-90311414-10-M1 is an W-Band, wide mechanical tuning bandwidth Gunn oscillator that utilizes a high-performance GaAs Gunn diode and proprietary cavity design to deliver +14 dBm typical power with low AM/FM noise and harmonic emissions. The oscillator has a center frequency of 97.5 GHz and a mechanical tuning range of ±7.5 GHz. It utilizes a fundamental Ka band broad tuning bandwidth Gunn oscillator and an active x3 multiplier to reach 90 to 105 GHz with +13 dBm output power. The Gunn oscillator is equipped with a micrometer for quick frequency tuning when used as a bench top unit. Models with a self-locking set screw for frequency tuning are available under a different model number for use in system integration applications. The performance of the oscillator can be further enhanced by adding an optional integrated isolator, Gunn oscillator modulator/regulator, and temperature heater.
