W-Band Varactor Tuned Gunn Oscillator

96 GHz, ±250 MHz Varactor Tuning Bandwidth, +16 dBm Output Power, WR-10 Waveguide
SKU:SOV-96305216-10-G1
SOV-96305216-10-G1 is a W-Band, Varactor tuned Gunn oscillator that utilizes a high performance GaAs Gunn diode and proprietary cavity design to deliver +16 dBm typical power. The oscillator features a Varactor tuning range of ±250 MHz and delivers low AM/FM noise and harmonic emissions. Compared to its counterparts, such as multiplier based sources, the Gunn oscillator is a lower cost and cleaner source. The performance of the oscillator can be further enhanced by adding an isolator, Gunn oscillator modulator/regulator and temperature heater.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency96 GHz
Output Power+16 dBm
Mechanical Tuning Range
Varactor Tuning Range±250 MHz
Bias+3.8 VDC/850 mA
Varactor Tuning Voltage Range4 to +25 VDC
RF PortWR-10 Waveguide
Varactor Tuning PortSMA (F)
